Solid stream jet CCP series nozzles

Pipe conn. size R1/4 Spray angle - Mean droplet diameter -
Strainer Not included Standard pressure 3 MPa Spray capacity 13.6–104 ℓ/min
Air consumption - Free passage diameter 2.0–5.4 mm

Features

• Our highest impact solid stream.
• Interior design featuring minimal pressure drop generates large flow of solid stream jet.
• Impact of turbulent flow inside the piping can be minimized.

Applications

• High pressure cleaning: Wire and felt parts of paper making machines, vehicles, returnable containers, machinery, parts
• Trimming: Paper making, asbestos plate

Industries in which this nozzle is used

• Machinery
• Paper & Pulp
• Printing
• Food

Product specifications

Structure • Made of metal, one-piece structure.
Material • Stainless steel 303
[Note] Use CCP series nozzles below the pressure of 3.5 MPa.
• Optional material: Stainless steel 316
Mass

20 g

Outer dimensions

CCP series

• Appearance and dimensions may differ slightly depending on materials and nozzle codes. Inquire with us for details.
